YALE 500kg 3phase Electric Hoist with Powered Trolley

YALE CPV5-8 500kg 3phase Electric Chain Hoist c/w Powered Trolley

Yale Trolley Hoist Specifications:

SWL: 500kg

Falls of chain: 1

Hoist speed: 8mtrs/min

Avaible from 3mtr HOL to 15mtr HOL

Single speed Powered Trolley (18mtrs/min)

The new YALE CPV Electric Chain Hoist combines modern design and technical innovation.  A robust construction makes the series a versatile tool for industrial applications.  Upper and lower limit switches considerably extend the working life span of the slipping clutch, motor and gearbox

Yale Trolley Hoist Features Include:-

• Load sprocket and chain guide can easily be inspected or removed, without disassembly of the complete unit
• Designed to FEM 1am. H3 (HMI)
• Main line contactor for increased safety
• Duty cycle 50% ED for single speed
• Electromagnetic spring pressure brake holds the load safely even in the event of power failure
• The externally adjustable slip clutch is designed to guarantee a permanent connection betweem the load and the brake
• Motor classification H3 and protected to IP 55 against ingress of dust and water jets
• Standard operating voltage: 400V, 3Ph, 50hz
• Increased operating safety through 42v low voltage control with encapsulated pendant control to IP 65
• Price includes Chainbag
• Fully tested and certified

For more information on our Yale Trolley Hoist, be sure to contact SafetyLiftinGear today!
