YALE CPV10-4 1000kg 3phase Electric Chain Hoist

Additional Information


*Specifications and prices may change from time to time so please confirm before placing your order.

YALE CPV10-4 1000kg 3phase Electric Chain Hoist

Product Code: CM-CPV10-4-RS

0 Review(s)

CMCO

Price Breaks:
See all quantity price breaks Click here for Net Weight

Was: £1,394.58
£1,162.15 (ex VAT)


Now: £1,212.68  Each inc VAT
(£1,010.57 ex VAT)
Options:
Qty:
Quantity:
1+
£1,010.57 ex Vat

YALE CPV10-4 1000kg 3phase Electric Chain Hoist

SWL: 1000kg

Falls of chain: 2

Hoist speed: 4mtrs/min

Avaible from 3mtr HOL to 15mtr HOL

The new YALE CPV Electric Chain Hoist combines modern design and technical innovation.  A robust construction makes the series a versatile tool for industrial applications.  Upper and lower limit switches considerably extend the working life span of the slipping clutch, motor and gearbox

Features include:-

  • Load sprocket and chain guide can easily be inspected or removed, without disassembly of the complete unit
  • Designed to FEM 1am. H3 (HMI)
  • Main line contactor for increased safety
  • Duty cycle 50% ED for single speed
  • Electromagnetic spring pressure brake holds the load safely even in the event of power failure
  • The externally adjustable slip clutch is designed to guarantee a permanent connection betweem the load and the brake
  • Motor classification H3 and protected to IP 55 against ingress of dust and water jets
  • Standard operating voltage: 400V, 3Ph, 50hz
  • Increased operating safety through 42v low voltage control with encapsulated pendant control to IP 65
  • Hook suspension

Fully tested and certified

DELIVERY IS 2-3 DAYS FROM DATE OF ORDER

YALE 1000kg 3phase Electric Chain Hoist HOL:03mtr (Net Weight Per Item: 28.00kg):
Quantity:
1+
(£1,010.57 ex Vat)
YALE 1000kg 3phase Electric Chain Hoist HOL:04mtr (Net Weight Per Item: 29.00kg):
Quantity:
1+
(£1,043.84 ex Vat)
YALE 1000kg 3phase Electric Chain Hoist HOL:06mtr (Net Weight Per Item: 30.00kg):
Quantity:
1+
(£1,110.40 ex Vat)
YALE 1000kg 3phase Electric Chain Hoist HOL:10mtr (Net Weight Per Item: 32.00kg):
Quantity:
1+
(£1,243.50 ex Vat)
YALE 1000kg 3phase Electric Chain Hoist HOL:12mtr (Net Weight Per Item: 34.00kg):
Quantity:
1+
(£1,310.06 ex Vat)
YALE 1000kg 3phase Electric Chain Hoist HOL:15mtr (Net Weight Per Item: 36.00kg):
Quantity:
1+
(£1,409.90 ex Vat)
