YALE CPV20-4 2000kg 3phase Electric Chain Hoist

More From This Brand

Add to New List

• Product Info

• YALE CPV20-4 2000kg 3phase 2-Fall Electric Chain Hoist

  SWL: 2000kg

  Falls of chain: 2

  Hoist speed: 4mtrs/min

  Avaible from 3mtr HOL to 10mtr HOL

  The new YALE CPV Electric Chain Hoist combines modern design and technical innovation.  A robust construction makes the series a versatile tool for industrial applications.  Upper and lower limit switches considerably extend the working life span of the slipping clutch, motor and gearbox

  Features include:-

  • Load sprocket and chain guide can easily be inspected or removed, without disassembly of the complete unit
  • Designed to FEM 1am. H3 (HMI)
  • Main line contactor for increased safety
  • Duty cycle 50% ED for single speed
  • Electromagnetic spring pressure brake holds the load safely even in the event of power failure
  • The externally adjustable slip clutch is designed to guarantee a permanent connection betweem the load and the brake
  • Motor classification H3 and protected to IP 55 against ingress of dust and water jets
  • Standard operating voltage: 400V, 3Ph, 50hz
  • Increased operating safety through 42v low voltage control with encapsulated pendant control to IP 65
  • Hook suspension
  • Single fall of chain
  • Price includes Chainbag
  • Fully tested and certified



• Specifications
• BrandCMCO

  Custom Made ProductYes

  Included in Return Policy No
  Additional Info
  Additional Information

  Specifications
• Price Breaks
• YALE 2000kg 3phase Single Fall Electric Chain Hoist HOL:03mtr (Net Weight Per Item: 63.00kg):

  Quantity:

  1+

  (£2,505.54 inc VAT)
  YALE 2000kg 3phase Single Fall Electric Chain Hoist HOL:04mtr (Net Weight Per Item: 67.00kg):

  Quantity:

  1+

  (£2,587.18 inc VAT)
  YALE 2000kg 3phase Single Fall Electric Chain Hoist HOL:06mtr (Net Weight Per Item: 75.00kg):

  Quantity:

  1+

  (£2,748.90 inc VAT)
  YALE 2000kg 3phase Single Fall Electric Chain Hoist HOL:10mtr (Net Weight Per Item: 91.00kg):

  Quantity:

  1+

  (£3,212.15 inc VAT)
