YALE CPV2-8 250kg 3phase Electric Chain Hoist

Product Code: CM-CPV2-8-RS
  • Product Info
  • YALE CPV2-8 250kg 3phase Electric Chain Hoist

    SWL: 250kg

    Falls of chain: 1

    Hoist speed: 8mtrs/min

    Avaible from 3mtr HOL to 15mtr HOL

    The new YALE CPV Electric Chain Hoist combines modern design and technical innovation.  A robust construction makes the series a versatile tool for industrial applications.  Upper and lower limit switches considerably extend the working life span of the slipping clutch, motor and gearbox

    Features include:-

    • Load sprocket and chain guide can easily be inspected or removed, without disassembly of the complete unit
    • Designed to FEM 1am. H3 (HMI)
    • Main line contactor for increased safety
    • Duty cycle 50% ED for single speed
    • Electromagnetic spring pressure brake holds the load safely even in the event of power failure
    • The externally adjustable slip clutch is designed to guarantee a permanent connection betweem the load and the brake
    • Motor classification H3 and protected to IP 55 against ingress of dust and water jets
    • Standard operating voltage: 400V, 3Ph, 50hz
    • Increased operating safety through 42v low voltage control with encapsulated pendant control to IP 65
    • Hook suspension
    • Price includes Chainbag
    • Fully tested and certified


  • Specifications
  • BrandCMCO
    Custom Made ProductYes
    Included in Return Policy No
    Additional Info
  • Price Breaks
  • YALE 250kg 3phase Electric Chain Hoist HOL:03mtr (Net Weight Per Item: 19.00kg):
    (£1,501.14 inc VAT)

  Exclusive Web Only Price!

Option code: CM-CPV2-8-RS-3M
£2,161.64£1,801.37 (ex VAT)
(£1,250.95 ex VAT)
